Fives STEEL (Fives DMS, Fives STEIN, Fives CELES, Fives ST) – ELECTRICAL STEEL
Electrical steel, also known as silicon steel, is a special steel tailored to achieve specific magnetic properties. It is used for high-end applications, such as e-vehicle or windmill motors, energy generators or power transformers, but its high silicon content makes it extremely sensitive to manufacturing.
LIFE-CHANGING TECHNOLOGY
With more than 90 references worldwide, Fives is your technology provider for a full range of electrical steel grades: NGO, GO and HiB.
Our know-how and proprietary technologies are capable of producing high flux density materials with minimum core losses at high frequencies.
⦁ Ultra-thin DMS 20Hi cold rolling mills
⦁ Electrical steel strip processing lines, including:
- AdvanTek® burners with low emissions
- Fast induction heating technology
- Precise furnace atmosphere control
- Compact rapid jet and mist cooling technology
NON-GRAIN ORIENTED STEEL (NGO)
Non-grain oriented (NGO) steel with high-efficiency magnetic properties and low iron loss involves a combination of process:
⦁ Annealing & Pickling Line (APL)
⦁ Cold Rolling Mill (CRM)
⦁ Annealing & Coating Line (ACL)
Fives' technology achieving record performances:
⦁ Strip Temperature: up to 1,100 °C
⦁ Process Speed: 200 mpm
⦁ H2 atmosphere: up to 100%
⦁ 0.1mm rolling thickness on full width
GRAIN ORIENTED STEEL (GO)
The production of grain oriented (GO) steel has an extremely high capital cost per ton and requires complex manufacturing and technology:
⦁ Annealing & Pickling Line (APL)
⦁ Cold Rolling Mill (CRM)
⦁ Decarburizing & Coating Line (DCL)
⦁ Flattening & Coating Line (FCL)
Fives' technology achieving record performances:
⦁ Strip Temperature: up to 1,100 °C
⦁ Process Speed: 160 mpm
⦁ H2 Atmosphere: up to 75%
